FG-300x2 FIXED FILTERING KIT 2" 50/15 µm water absorbent
Liquids: Diesel Diesel  Petrol Petrol Biodiesel Biodiesel
FG-300x2 Fixed Filtering Kit · 50/15 µm · 2"
  • Two-phase filtration kits designed for the fuel (diesel, petrol, kerosene and oil) filtering of buried or aerial tanks, getting the microfiltered fluid free of impurities.
  • First filtration phase of 50 µm (micron)
  • Second filtration phase for water absorption and impurity filtration of 15 µm (micron)
  • Special superficial interior and external finish against corrosion.


The kits are composed of:

  • 1 fixed platform
  • 2 manual drain valves to eliminate the residual air
  • 2 differential manometers which show when the filter has to be replaced or cleaned
  • 2 outlets for the filtered liquid sampling
  • 2 inlets for the connection of compressed air to clean the filters without being disassembled
  • 1 Ø150x458 mm impact filtering element of 50 µm (micron)
  • 1 final element of absorbent paper of 15 µm (micron)
Size and weight (approx.):

Size: 999x400x843mm (length x width x height)
Weight: 55.5Kg
